    50W Thermopile Power Detector with 10kW Maximum Average Power Density and ODM Options

    Ask Lasest Price
    Brand Name : YIXIST
    Model Number : YPM-8203-02-FL
    Price : $1,254.00/pieces >=1 pieces
    • Product Details
    • Company Profile

    50W Thermopile Power Detector with 10kW Maximum Average Power Density and ODM Options

    50W Thermopile Power Detector with 10kW Maximum Average Power Density and ODM Options
    PRODUCT OVERVIEW
    The Thermopile Power Detector is specifically engineered for accurately measuring laser power levels between 0.05W and 50W. To accommodate various user preferences, the detector presents two data acquisition alternatives: a DB15 connection featuring a meter display, and a Bluetooth/USB connection enabling seamless computer integration.

    YPM-8203-02-F-L uses DB15 interface, which need to connect the power meters.It can be used on the meter for data reading, data storage and power monitoring. In addition, a USB communication interface is reserved on the meter, which can expand the data collected on the detector and upload the data to the optical power meter software on the PC for online data acquisition and analysis.

    Calibration

    Every detector undergoes individual calibration and is accompanied by a factory calibration certificate, with the calibration data stored directly on the detector itself.
    We offer calibration services, and to guarantee precise measurements, we recommend calibrating the detector annually.

    Customized service

    We can provide customized services according to user requirements.
    PRODUCT SPECIFICATIONS
    Model
    YPM-8203-02-0002-F-L
    Connect
    DB15 With the power meter
    Material
    Thermopile
    Wavelength range
    0.19-20um
    Max Average Power Density
    10kW/cm2(1064nm/10W/CW)
    3.2kW/cm2(10640nm/10W/CW)
    Maximum Energy Density
    5J/cm2(1064nm,360us,5Hz)
    1J/cm2(1064nm,7ns,10Hz)
    0.6J/cm2(532nm,7ns,10Hz)
    0.3J/cm2(266nm,7ns,10Hz)
    Maximum Average Power
    (Typical value)
    50W(continuous);
    70W(<1minute)
    Power range
    0.05-50W
    Calibration Uncertainty
    ±3%@1064nm, 10640nm
    ±5%@190-20000 nm
    Linearity
    ±2%
    Uniformity
    ±2%
    Response Time
    3s
    Active Diameter
    10mm
    Cooling
    Fan
    Dimensions(L*W*D)
    70 mm×70 mm×70 mm
    DIMENSION
    50W Thermopile Power Detector with 10kW Maximum Average Power Density and ODM Options
    50W Thermopile Power Detector with 10kW Maximum Average Power Density and ODM Options
    RELATED ACCESSORIES
    50W Thermopile Power Detector with 10kW Maximum Average Power Density and ODM Options
    Power Meter
    50W Thermopile Power Detector with 10kW Maximum Average Power Density and ODM Options
    Integrating Sphere Power Detector
    50W Thermopile Power Detector with 10kW Maximum Average Power Density and ODM Options
    Photodetector
    COMPANY PROFILE
    50W Thermopile Power Detector with 10kW Maximum Average Power Density and ODM Options
    YIXI Smart Technology (YIXIST) Co., Ltd.
    YIXIST is an innovative technology enterprise based on advanced optical measurement technology, which is determined to become the best supplier and advanced technology provider in the intelligent equipment manufacturing industry to create the greatest value for customers globally.
    50W Thermopile Power Detector with 10kW Maximum Average Power Density and ODM Options
    50W Thermopile Power Detector with 10kW Maximum Average Power Density and ODM Options
    50W Thermopile Power Detector with 10kW Maximum Average Power Density and ODM Options
    50W Thermopile Power Detector with 10kW Maximum Average Power Density and ODM Options
    Currently we're working with hunderds of well known universities and research institutions in China and are actively involved in offline events as Education Seminars and Exhibitions.
